Product details
LabTech company separate circulating water cooler, the use of well-known manufacturers efficient compressor units, excellent performance, matching high quality motor, smooth operation, low noise, high efficiency, excellent performance of the body, longer life, more energy saving. Even in winter-25 ℃ still can start, really achieve the equipment at any time start and stop, anytime application, use and operation more convenient and fast. It is widely used in X-ray diffraction spectrometer, infrared spectrometer, differential thermal analyzer, nuclear magnetic resonance (MRI), fatigue tester, vacuum coating machine and so on.
Technical specifications
Temperature control range 8 ℃ 35 ℃
Temperature control mode PID
Temperature stability ±2 ℃
Refrigeration capacity 5000W
Pump flow 17.1L/min@4Bar
Water tank capacity 13L
Unit size (L × W × H) 720 × 460 × 660mm
Outdoor unit size (L × W × H) 710 × 560 × 500mmLabTech HF500 split Chiller
Application example
